| Parameters | Unit | Spcecifications | ||
| Min. | Type. | Max. | ||
| Average Power | W | 0.5W | ||
| Laser Central Wavelength | nm | 1533 | 1535 | 1536 |
| Pulse Width (FWHM) | ns | 2 | 10 | |
|
Pulse Repetition Frequency (PRF) |
MHz | 0.5 | 1.0 | 2 |
|
Pulse Peak Power |
kW | 0.25(0.5) | ||
| ASE | % | 10 | ||
|
Output Polarization |
Random | |||
|
Output Fiber |
Clear Curve ZBL |
|||
| Output Fiber Length | cm | 30 or cutomized | ||
| Operating Temperature | ℃ | -40 | 85 | |
| Storage Temperature | ℃ |
-40 | 105 | |
| Output Beam Quality Factor | M2 | 1.1 | ||
| Power Consumption | W | 4 | 10 | |
| Fiber Termination | FC/APC or custom |
|||
车规级认证--ISO 16750/IEC 60068和ISTA 3A 小尺寸: ≥50*55*19mm3 人眼安全 温度范围: -40°~105° 2022年一大批量交付 低功耗: < 10W 测距: 200~1000米
Ultra-compact Size Long-distance Rangefinder 15KM Eye-safe Low Cost
High Precision Optical Reflecting Deflecting Displacement Rotation and Dispersion Prisms are choosen by Microscopes, Optical Instruments, Binoculars, Telescopes, Periscopes, Surveyring equipements and many sophisticated Scientific Instruments including Interferometers, Spectrophotometers and Fluorimeters.
Hitronics is the No.1 supplier of Cylindrical lens in the global market with capacity more than 3 millions per month. The series of products are full in styles: FAC (fast-axis collimator lens) SAC (slow-axis collimator lens) Cylindrical Lenses Spherical and Cylindrical Lenses Acylindrical Lenses
